Waterproof a large tank
Sealant Boiler
RSG-200 as a 2008 model and external design, ease of use has been further upgraded.
| Category | Detail |
|---|---|
| Produced Company | Roadseal.Co.Ltd. |
| Model | RSG-200 |
| Tank Storage Capacity | 200GL |
| Used fuel | Diesel |
| Heating fluid | Heat medium fluid |
| Driving method | trailer type |
| Boiler working temperature | 180-230℃ |
| Boiler maximum temperature | less than 250℃ |
| Using engine | KOHLER 25HP |
| Size(mm) | 4,500 x 2,250 x 1,800 |
Sealant Boiler(Loading type)
AUTOBOI is the movable boiler that easily heat up the Roadseal to fix the crack parts in the road or to construct the bridge joint.
| Category | Detail |
|---|---|
| Produced Company | Roadseal.Co.Ltd. |
| Model | RSD120-LD |
| Tank Storage Capacity | 200GL |
| Used fuel | Diesel |
| Heating fluid | Heat medium fluid |
| Driving method | Loading type |
| Boiler working temperature | 160~230℃ |
| Boiler maximum temperature | less than 250℃ |
| Using engine | Diesel |
| Size(mm) | 4,640 x 1,800 |
Sealant Boiler
AUTOBOI is the movable boiler that easily heat up the Roadseal to fix the crack parts in the road or to construct the bridge joint
| Category | Detail |
|---|---|
| Produced Company | Roadseal.Co.Ltd. |
| Model | RSD-125 |
| Tank Storage Capacity | 120GL |
| Used fuel | Diesel |
| Heating fluid | Heat medium fluid |
| Driving method | trailer type |
| Boiler working temperature | 160~230℃ |
| Boiler maximum temperature | less than 250℃ |
| Using engine | Diesel |
| Size(mm) | 3,000 x 1,220 x 1,950 |
Router
Router can cut the crack when seal the cracks in asphalt and concrete road.
| Category | Detail |
|---|---|
| Produced Company | Roadseal.Co.Ltd. |
| Model | RSR-101 ROUTER |
| Cutting method | cutting method by cutter action |
| power transmitting method for cutter | V belt power transmitting method |
| transporting method | man power towing method |
| using engine | KOHLER 25HP |
| size(mm) | 1,900 x 850 x 1,000 |
Mixer(Large)
Structures during construction expansion joint sealant dry compound when mixed with aggregate and used equipment
(Capacity : 1ton)
Mixer(Medium)
This equipment is used when mixing washed aggregate and sealant for bridge elastic joint. This aggregate mixer has single phase 3HP 220V electric motor attached, so 10HP generator is required. Also when too much aggregate is poured, mixing will be difficult, and mixer can be damaged. About 100kg of aggregate should be put in.
Heatransor
Heatransor clean up the dust and damp air created after cutting from fans to increase the cohesiveness of sealant. Heatransor clean up the dust and heat up the road at the same time to reduce the cost of workers, and only by passing it to the surface of the road, it will increase the cohesiveness of sealant. Use it in the rainy season with the other heating equipments like LPG or oxygen torch to remove the damp air completely. Heatransor is connected to air compressor to use, and air compressor should have capacity of 2.5~4.5㎥/min (30~50HP).
High Pressure Cleaner
After cutting gutters and walls to remove dust and dirt attached to the equipment
